5. Vectorize, parallelize, unroll and tile your code#

C++

// Halide tutorial lesson 5: Vectorize, parallelize, unroll and tile your code

// This lesson demonstrates how to manipulate the order in which you
// evaluate pixels in a Func, including vectorization,
// parallelization, unrolling, and tiling.

// On linux, you can compile and run it like so:
// g++ lesson_05*.cpp -g -I <path/to/include> -L <path/to/lib> -lHalide -lpthread -ldl -o lesson_05 -std=c++17
// LD_LIBRARY_PATH=<path/to/lib> ./lesson_05

// On macOS:
// g++ lesson_05*.cpp -g -I <path/to/include> -L <path/to/lib> -lHalide -o lesson_05 -std=c++17
// DYLD_LIBRARY_PATH=<path/to/lib> ./lesson_05

#include "Halide.h"
#include <algorithm>
#include <cstdio>
using namespace Halide;

int main() {

    // We're going to define and schedule our gradient function in
    // several different ways, and see what order pixels are computed
    // in.

    Var x("x"), y("y");

    // First we observe the default ordering.
    {
        Func gradient("gradient");
        gradient(x, y) = x + y;
        gradient.trace_stores();

        // By default we walk along the rows and then down the
        // columns. This means x varies quickly, and y varies
        // slowly. x is the column and y is the row, so this is a
        // row-major traversal.
        printf("Evaluating gradient row-major\n");
        Buffer<int> output = gradient.realize({4, 4});

        // See below for a visualization of
        // what this did.

        // The equivalent C is:
        printf("Equivalent C:\n");
        for (int y = 0; y < 4; y++) {
            for (int x = 0; x < 4; x++) {
                printf("Evaluating at x = %d, y = %d: %d\n", x, y, x + y);
            }
        }
        printf("\n\n");

        // Tracing is one useful way to understand what a schedule is
        // doing. You can also ask Halide to print out pseudocode
        // showing what loops Halide is generating:
        printf("Pseudo-code for the schedule:\n");
        gradient.print_loop_nest();

        printf("\n");

        // Because we're using the default ordering, it should print:
        // compute gradient:
        //   for y:
        //     for x:
        //       gradient(...) = ...
    }

    // Reorder variables.
    {
        Func gradient("gradient_col_major");
        gradient(x, y) = x + y;
        gradient.trace_stores();

        // If we reorder x and y, we can walk down the columns
        // instead. The reorder call takes the arguments of the func,
        // and sets a new nesting order for the for loops that are
        // generated. The arguments are specified from the innermost
        // loop out, so the following call puts y in the inner loop:
        gradient.reorder(y, x);

        // This means y (the row) will vary quickly, and x (the
        // column) will vary slowly, so this is a column-major
        // traversal.

        printf("Evaluating gradient column-major\n");
        Buffer<int> output = gradient.realize({4, 4});

        // See below for a visualization of
        // what this did.

        printf("Equivalent C:\n");
        for (int x = 0; x < 4; x++) {
            for (int y = 0; y < 4; y++) {
                printf("Evaluating at x = %d, y = %d: %d\n", x, y, x + y);
            }
        }
        printf("\n");

        // If we print pseudo-code for this schedule, we'll see that
        // the loop over y is now inside the loop over x.
        printf("Pseudo-code for the schedule:\n");
        gradient.print_loop_nest();

        printf("\n");
    }

    // Split a variable into two.
    {
        Func gradient("gradient_split");
        gradient(x, y) = x + y;
        gradient.trace_stores();

        // The most powerful primitive scheduling operation you can do
        // to a var is to split it into inner and outer sub-variables:
        Var x_outer, x_inner;
        gradient.split(x, x_outer, x_inner, 2);

        // This breaks the loop over x into two nested loops: an outer
        // one over x_outer, and an inner one over x_inner. The last
        // argument to split was the "split factor". The inner loop
        // runs from zero to the split factor. The outer loop runs
        // from zero to the extent required of x (4 in this case)
        // divided by the split factor. Within the loops, the old
        // variable is defined to be outer * factor + inner. If the
        // old loop started at a value other than zero, then that is
        // also added within the loops.

        printf("Evaluating gradient with x split into x_outer and x_inner \n");
        Buffer<int> output = gradient.realize({4, 4});

        printf("Equivalent C:\n");
        for (int y = 0; y < 4; y++) {
            for (int x_outer = 0; x_outer < 2; x_outer++) {
                for (int x_inner = 0; x_inner < 2; x_inner++) {
                    int x = x_outer * 2 + x_inner;
                    printf("Evaluating at x = %d, y = %d: %d\n", x, y, x + y);
                }
            }
        }
        printf("\n");

        printf("Pseudo-code for the schedule:\n");
        gradient.print_loop_nest();

        printf("\n");

        // Note that the order of evaluation of pixels didn't actually
        // change! Splitting by itself does nothing, but it does open
        // up all of the scheduling possibilities that we will explore
        // below.
    }

    // Fuse two variables into one.
    {
        Func gradient("gradient_fused");
        gradient(x, y) = x + y;

        // The opposite of splitting is 'fusing'. Fusing two variables
        // merges the two loops into a single for loop over the
        // product of the extents. Fusing is less important than
        // splitting, but it also sees use (as we'll see later in this
        // lesson). Like splitting, fusing by itself doesn't change
        // the order of evaluation.
        Var fused;
        gradient.fuse(x, y, fused);

        printf("Evaluating gradient with x and y fused\n");
        Buffer<int> output = gradient.realize({4, 4});

        printf("Equivalent C:\n");
        for (int fused = 0; fused < 4 * 4; fused++) {
            int y = fused / 4;
            int x = fused % 4;
            printf("Evaluating at x = %d, y = %d: %d\n", x, y, x + y);
        }
        printf("\n");

        printf("Pseudo-code for the schedule:\n");
        gradient.print_loop_nest();

        printf("\n");
    }

    // Evaluating in tiles.
    {
        Func gradient("gradient_tiled");
        gradient(x, y) = x + y;
        gradient.trace_stores();

        // Now that we can both split and reorder, we can do tiled
        // evaluation. Let's split both x and y by a factor of four,
        // and then reorder the vars to express a tiled traversal.
        //
        // A tiled traversal splits the domain into small rectangular
        // tiles, and outermost iterates over the tiles, and within
        // that iterates over the points within each tile. It can be
        // good for performance if neighboring pixels use overlapping
        // input data, for example in a blur. We can express a tiled
        // traversal like so:
        Var x_outer, x_inner, y_outer, y_inner;
        gradient.split(x, x_outer, x_inner, 4);
        gradient.split(y, y_outer, y_inner, 4);
        gradient.reorder(x_inner, y_inner, x_outer, y_outer);

        // This pattern is common enough that there's a shorthand for it:
        // gradient.tile(x, y, x_outer, y_outer, x_inner, y_inner, 4, 4);

        printf("Evaluating gradient in 4x4 tiles\n");
        Buffer<int> output = gradient.realize({8, 8});

        // See below for a visualization of this
        // schedule.

        printf("Equivalent C:\n");
        for (int y_outer = 0; y_outer < 2; y_outer++) {
            for (int x_outer = 0; x_outer < 2; x_outer++) {
                for (int y_inner = 0; y_inner < 4; y_inner++) {
                    for (int x_inner = 0; x_inner < 4; x_inner++) {
                        int x = x_outer * 4 + x_inner;
                        int y = y_outer * 4 + y_inner;
                        printf("Evaluating at x = %d, y = %d: %d\n", x, y, x + y);
                    }
                }
            }
        }
        printf("\n");

        printf("Pseudo-code for the schedule:\n");
        gradient.print_loop_nest();

        printf("\n");
    }

    // Evaluating in vectors.
    {
        Func gradient("gradient_in_vectors");
        gradient(x, y) = x + y;
        gradient.trace_stores();

        // The nice thing about splitting is that it guarantees the
        // inner variable runs from zero to the split factor. Most of
        // the time the split-factor will be a compile-time constant,
        // so we can replace the loop over the inner variable with a
        // single vectorized computation. This time we'll split by a
        // factor of four, because on X86 we can use SSE to compute in
        // 4-wide vectors.
        Var x_outer, x_inner;
        gradient.split(x, x_outer, x_inner, 4);
        gradient.vectorize(x_inner);

        // Splitting and then vectorizing the inner variable is common
        // enough that there's a short-hand for it. We could have also
        // said:
        //
        // gradient.vectorize(x, 4);
        //
        // which is equivalent to:
        //
        // gradient.split(x, x, x_inner, 4);
        // gradient.vectorize(x_inner);
        //
        // Note that in this case we reused the name 'x' as the new
        // outer variable. Later scheduling calls that refer to x
        // will refer to this new outer variable named x.

        // This time we'll evaluate over an 8x4 box, so that we have
        // more than one vector of work per scanline.
        printf("Evaluating gradient with x_inner vectorized \n");
        Buffer<int> output = gradient.realize({8, 4});

        // See below for a visualization.

        printf("Equivalent C:\n");
        for (int y = 0; y < 4; y++) {
            for (int x_outer = 0; x_outer < 2; x_outer++) {
                // The loop over x_inner has gone away, and has been
                // replaced by a vectorized version of the
                // expression. On x86 processors, Halide generates SSE
                // for all of this.
                int x_vec[] = {x_outer * 4 + 0,
                               x_outer * 4 + 1,
                               x_outer * 4 + 2,
                               x_outer * 4 + 3};
                int val[] = {x_vec[0] + y,
                             x_vec[1] + y,
                             x_vec[2] + y,
                             x_vec[3] + y};
                printf("Evaluating at <%d, %d, %d, %d>, <%d, %d, %d, %d>:"
                       " <%d, %d, %d, %d>\n",
                       x_vec[0], x_vec[1], x_vec[2], x_vec[3],
                       y, y, y, y,
                       val[0], val[1], val[2], val[3]);
            }
        }
        printf("\n");

        printf("Pseudo-code for the schedule:\n");
        gradient.print_loop_nest();

        printf("\n");
    }

    // Unrolling a loop.
    {
        Func gradient("gradient_unroll");
        gradient(x, y) = x + y;
        gradient.trace_stores();

        // If multiple pixels share overlapping data, it can make
        // sense to unroll a computation so that shared values are
        // only computed or loaded once. We do this similarly to how
        // we expressed vectorizing. We split a dimension and then
        // fully unroll the loop of the inner variable. Unrolling
        // doesn't change the order in which things are evaluated.
        Var x_outer, x_inner;
        gradient.split(x, x_outer, x_inner, 2);
        gradient.unroll(x_inner);

        // The shorthand for this is:
        // gradient.unroll(x, 2);

        printf("Evaluating gradient unrolled by a factor of two\n");
        Buffer<int> result = gradient.realize({4, 4});

        printf("Equivalent C:\n");
        for (int y = 0; y < 4; y++) {
            for (int x_outer = 0; x_outer < 2; x_outer++) {
                // Instead of a for loop over x_inner, we get two
                // copies of the innermost statement.
                {
                    int x_inner = 0;
                    int x = x_outer * 2 + x_inner;
                    printf("Evaluating at x = %d, y = %d: %d\n", x, y, x + y);
                }
                {
                    int x_inner = 1;
                    int x = x_outer * 2 + x_inner;
                    printf("Evaluating at x = %d, y = %d: %d\n", x, y, x + y);
                }
            }
        }
        printf("\n");

        printf("Pseudo-code for the schedule:\n");
        gradient.print_loop_nest();

        printf("\n");
    }

    // Splitting by factors that don't divide the extent.
    {
        Func gradient("gradient_split_7x2");
        gradient(x, y) = x + y;
        gradient.trace_stores();

        // Splitting guarantees that the inner loop runs from zero to
        // the split factor, which is important for the uses we saw
        // above. So what happens when the total extent we wish to
        // evaluate x over isn't a multiple of the split factor? We'll
        // split by a factor three, and we'll evaluate gradient over a
        // 7x2 box instead of the 4x4 box we've been using.
        Var x_outer, x_inner;
        gradient.split(x, x_outer, x_inner, 3);

        printf("Evaluating gradient over a 7x2 box with x split by three \n");
        Buffer<int> output = gradient.realize({7, 2});

        // See below for a visualization
        // of what happened. Note that some points get evaluated more
        // than once!

        printf("Equivalent C:\n");
        for (int y = 0; y < 2; y++) {
            for (int x_outer = 0; x_outer < 3; x_outer++) {  // Now runs from 0 to 2
                for (int x_inner = 0; x_inner < 3; x_inner++) {
                    int x = x_outer * 3;
                    // Before we add x_inner, make sure we don't
                    // evaluate points outside of the 7x2 box. We'll
                    // clamp x to be at most 4 (7 minus the split
                    // factor).
                    if (x > 4) { x = 4; }
                    x += x_inner;
                    printf("Evaluating at x = %d, y = %d: %d\n", x, y, x + y);
                }
            }
        }
        printf("\n");

        printf("Pseudo-code for the schedule:\n");
        gradient.print_loop_nest();

        printf("\n");

        // If you read the output, you'll see that some coordinates
        // were evaluated more than once. That's generally OK, because
        // pure Halide functions have no side-effects, so it's safe to
        // evaluate the same point multiple times. If you're calling
        // out to C functions like we are, it's your responsibility to
        // make sure you can handle the same point being evaluated
        // multiple times.

        // The general rule is: If we require x from x_min to x_min + x_extent, and
        // we split by a factor 'factor', then:
        //
        // x_outer runs from 0 to (x_extent + factor - 1)/factor
        // x_inner runs from 0 to factor
        // x = min(x_outer * factor, x_extent - factor) + x_inner + x_min
        //
        // In our example, x_min was 0, x_extent was 7, and factor was 3.

        // However, if you write a Halide function with an update
        // definition (see lesson 9), then it is not safe to evaluate
        // the same point multiple times, so we won't apply this
        // trick. Instead the range of values computed will be rounded
        // up to the next multiple of the split factor.
    }

    // Fusing, tiling, and parallelizing.
    {
        // We saw in the previous lesson that we can parallelize
        // across a variable. Here we combine it with fusing and
        // tiling to express a useful pattern - processing tiles in
        // parallel.

        // This is where fusing shines. Fusing helps when you want to
        // parallelize across multiple dimensions without introducing
        // nested parallelism. Nested parallelism (parallel for loops
        // within parallel for loops) is supported by Halide, but
        // often gives poor performance compared to fusing the
        // parallel variables into a single parallel for loop.

        Func gradient("gradient_fused_tiles");
        gradient(x, y) = x + y;
        gradient.trace_stores();

        // First we'll tile, then we'll fuse the tile indices and
        // parallelize across the combination.
        Var x_outer, y_outer, x_inner, y_inner, tile_index;
        gradient.tile(x, y, x_outer, y_outer, x_inner, y_inner, 4, 4);
        gradient.fuse(x_outer, y_outer, tile_index);
        gradient.parallel(tile_index);

        // The scheduling calls all return a reference to the Func, so
        // you can also chain them together into a single statement to
        // make things slightly clearer:
        //
        // gradient
        //     .tile(x, y, x_outer, y_outer, x_inner, y_inner, 4, 4)
        //     .fuse(x_outer, y_outer, tile_index)
        //     .parallel(tile_index);

        printf("Evaluating gradient tiles in parallel\n");
        Buffer<int> output = gradient.realize({8, 8});

Show output

Begin pipeline gradient_fused_tiles.0()
Tag gradient_fused_tiles.0() tag = "func_type_and_dim: 1 0 32 1 2 0 8 0 8"
Begin parallel task gradient_fused_tiles.s0.x.v13.v17.0(0, 4) thread_id = 45075
Store gradient_fused_tiles.0(0, 0) = 0
Store gradient_fused_tiles.0(1, 0) = 1
Store gradient_fused_tiles.0(2, 0) = 2
Store gradient_fused_tiles.0(3, 0) = 3
Store gradient_fused_tiles.0(0, 1) = 1
Store gradient_fused_tiles.0(1, 1) = 2
Store gradient_fused_tiles.0(2, 1) = 3
Store gradient_fused_tiles.0(3, 1) = 4
Store gradient_fused_tiles.0(0, 2) = 2
Store gradient_fused_tiles.0(1, 2) = 3
Store gradient_fused_tiles.0(2, 2) = 4
Store gradient_fused_tiles.0(3, 2) = 5
Store gradient_fused_tiles.0(0, 3) = 3
Store gradient_fused_tiles.0(1, 3) = 4
Store gradient_fused_tiles.0(2, 3) = 5
Store gradient_fused_tiles.0(3, 3) = 6
End parallel task gradient_fused_tiles.s0.x.v13.v17.0(0, 4)
Begin parallel task gradient_fused_tiles.s0.x.v13.v17.0(0, 4) thread_id = 45075
Store gradient_fused_tiles.0(4, 0) = 4
Store gradient_fused_tiles.0(5, 0) = 5
Store gradient_fused_tiles.0(6, 0) = 6
Store gradient_fused_tiles.0(7, 0) = 7
Store gradient_fused_tiles.0(4, 1) = 5
Store gradient_fused_tiles.0(5, 1) = 6
Store gradient_fused_tiles.0(6, 1) = 7
Store gradient_fused_tiles.0(7, 1) = 8
Store gradient_fused_tiles.0(4, 2) = 6
Store gradient_fused_tiles.0(5, 2) = 7
Store gradient_fused_tiles.0(6, 2) = 8
Store gradient_fused_tiles.0(7, 2) = 9
Store gradient_fused_tiles.0(4, 3) = 7
Store gradient_fused_tiles.0(5, 3) = 8
Store gradient_fused_tiles.0(6, 3) = 9
Store gradient_fused_tiles.0(7, 3) = 10
End parallel task gradient_fused_tiles.s0.x.v13.v17.0(0, 4)
Begin parallel task gradient_fused_tiles.s0.x.v13.v17.0(0, 4) thread_id = 45075
Store gradient_fused_tiles.0(0, 4) = 4
Store gradient_fused_tiles.0(1, 4) = 5
Store gradient_fused_tiles.0(2, 4) = 6
Store gradient_fused_tiles.0(3, 4) = 7
Store gradient_fused_tiles.0(0, 5) = 5
Store gradient_fused_tiles.0(1, 5) = 6
Store gradient_fused_tiles.0(2, 5) = 7
Store gradient_fused_tiles.0(3, 5) = 8
Store gradient_fused_tiles.0(0, 6) = 6
Store gradient_fused_tiles.0(1, 6) = 7
Store gradient_fused_tiles.0(2, 6) = 8
Store gradient_fused_tiles.0(3, 6) = 9
Store gradient_fused_tiles.0(0, 7) = 7
Store gradient_fused_tiles.0(1, 7) = 8
Store gradient_fused_tiles.0(2, 7) = 9
Store gradient_fused_tiles.0(3, 7) = 10
End parallel task gradient_fused_tiles.s0.x.v13.v17.0(0, 4)
Begin parallel task gradient_fused_tiles.s0.x.v13.v17.0(0, 4) thread_id = 45075
Store gradient_fused_tiles.0(4, 4) = 8
Store gradient_fused_tiles.0(5, 4) = 9
Store gradient_fused_tiles.0(6, 4) = 10
Store gradient_fused_tiles.0(7, 4) = 11
Store gradient_fused_tiles.0(4, 5) = 9
Store gradient_fused_tiles.0(5, 5) = 10
Store gradient_fused_tiles.0(6, 5) = 11
Store gradient_fused_tiles.0(7, 5) = 12
Store gradient_fused_tiles.0(4, 6) = 10
Store gradient_fused_tiles.0(5, 6) = 11
Store gradient_fused_tiles.0(6, 6) = 12
Store gradient_fused_tiles.0(7, 6) = 13
Store gradient_fused_tiles.0(4, 7) = 11
Store gradient_fused_tiles.0(5, 7) = 12
Store gradient_fused_tiles.0(6, 7) = 13
Store gradient_fused_tiles.0(7, 7) = 14
End parallel task gradient_fused_tiles.s0.x.v13.v17.0(0, 4)
End pipeline gradient_fused_tiles.0()

        // The tiles should occur in arbitrary order, but within each
        // tile the pixels will be traversed in row-major order. See
        // below for a visualization.

        printf("Equivalent (serial) C:\n");
        // This outermost loop should be a parallel for loop, but that's hard in C.
        for (int tile_index = 0; tile_index < 4; tile_index++) {
            int y_outer = tile_index / 2;
            int x_outer = tile_index % 2;
            for (int y_inner = 0; y_inner < 4; y_inner++) {
                for (int x_inner = 0; x_inner < 4; x_inner++) {
                    int y = y_outer * 4 + y_inner;
                    int x = x_outer * 4 + x_inner;
                    printf("Evaluating at x = %d, y = %d: %d\n", x, y, x + y);
                }
            }
        }
        printf("\n");

        printf("Pseudo-code for the schedule:\n");
        gradient.print_loop_nest();

        printf("\n");
    }

    // Putting it all together.
    {
        // Are you ready? We're going to use all of the features above now.
        Func gradient_fast("gradient_fast");
        gradient_fast(x, y) = x + y;

        // We'll process 64x64 tiles in parallel.
        Var x_outer, y_outer, x_inner, y_inner, tile_index;
        gradient_fast
            .tile(x, y, x_outer, y_outer, x_inner, y_inner, 64, 64)
            .fuse(x_outer, y_outer, tile_index)
            .parallel(tile_index);

        // We'll compute two scanlines at once while we walk across
        // each tile. We'll also vectorize in x. The easiest way to
        // express this is to recursively tile again within each tile
        // into 4x2 subtiles, then vectorize the subtiles across x and
        // unroll them across y:
        Var x_inner_outer, y_inner_outer, x_vectors, y_pairs;
        gradient_fast
            .tile(x_inner, y_inner, x_inner_outer, y_inner_outer, x_vectors, y_pairs, 4, 2)
            .vectorize(x_vectors)
            .unroll(y_pairs);

        // Note that we didn't do any explicit splitting or
        // reordering. Those are the most important primitive
        // operations, but mostly they are buried underneath tiling,
        // vectorizing, or unrolling calls.

        // Now let's evaluate this over a range which is not a
        // multiple of the tile size.

        // If you like you can turn on tracing, but it's going to
        // produce a lot of printfs. Instead we'll compute the answer
        // both in C and Halide and see if the answers match.
        Buffer<int> result = gradient_fast.realize({350, 250});

        // See below for a visualization.

        printf("Checking Halide result against equivalent C...\n");
        for (int tile_index = 0; tile_index < 6 * 4; tile_index++) {
            int y_outer = tile_index / 4;
            int x_outer = tile_index % 4;
            for (int y_inner_outer = 0; y_inner_outer < 64 / 2; y_inner_outer++) {
                for (int x_inner_outer = 0; x_inner_outer < 64 / 4; x_inner_outer++) {
                    // We're vectorized across x
                    int x = std::min(x_outer * 64, 350 - 64) + x_inner_outer * 4;
                    int x_vec[4] = {x + 0,
                                    x + 1,
                                    x + 2,
                                    x + 3};

                    // And we unrolled across y
                    int y_base = std::min(y_outer * 64, 250 - 64) + y_inner_outer * 2;
                    {
                        // y_pairs = 0
                        int y = y_base + 0;
                        int y_vec[4] = {y, y, y, y};
                        int val[4] = {x_vec[0] + y_vec[0],
                                      x_vec[1] + y_vec[1],
                                      x_vec[2] + y_vec[2],
                                      x_vec[3] + y_vec[3]};

                        // Check the result.
                        for (int i = 0; i < 4; i++) {
                            if (result(x_vec[i], y_vec[i]) != val[i]) {
                                printf("There was an error at %d %d!\n",
                                       x_vec[i], y_vec[i]);
                                return -1;
                            }
                        }
                    }
                    {
                        // y_pairs = 1
                        int y = y_base + 1;
                        int y_vec[4] = {y, y, y, y};
                        int val[4] = {x_vec[0] + y_vec[0],
                                      x_vec[1] + y_vec[1],
                                      x_vec[2] + y_vec[2],
                                      x_vec[3] + y_vec[3]};

                        // Check the result.
                        for (int i = 0; i < 4; i++) {
                            if (result(x_vec[i], y_vec[i]) != val[i]) {
                                printf("There was an error at %d %d!\n",
                                       x_vec[i], y_vec[i]);
                                return -1;
                            }
                        }
                    }
                }
            }
        }
        printf("\n");

        printf("Pseudo-code for the schedule:\n");
        gradient_fast.print_loop_nest();

        printf("\n");

        // Note that in the Halide version, the algorithm is specified
        // once at the top, separately from the optimizations, and there
        // aren't that many lines of code total. Compare this to the C
        // version. There's more code (and it isn't even parallelized or
        // vectorized properly). More annoyingly, the statement of the
        // algorithm (the result is x plus y) is buried in multiple places
        // within the mess. This C code is hard to write, hard to read,
        // hard to debug, and hard to optimize further. This is why Halide
        // exists.
    }

    printf("Success!\n");
    return 0;
}

Python

#!/usr/bin/python3

# Halide tutorial lesson 5

# This lesson demonstrates how to manipulate the order in which you
# evaluate pixels in a hl.Func, including vectorization,
# parallelization, unrolling, and tiling.

import halide as hl


def main():
    # We're going to define and schedule our gradient function in
    # several different ways, and see what order pixels are computed
    # in.

    x, y = hl.Var("x"), hl.Var("y")

    # First we observe the default ordering.
    if True:
        gradient = hl.Func("gradient")
        gradient[x, y] = x + y
        gradient.trace_stores()

        # By default we walk along the rows and then down the
        # columns. This means x varies quickly, and y varies
        # slowly. x is the column and y is the row, so this is a
        # row-major traversal.
        print("Evaluating gradient row-major")
        gradient.realize([4, 4])

        # The equivalent Python is:
        print("Equivalent Python:")
        for yy in range(4):
            for xx in range(4):
                print(f"Evaluating at x = {xx}, y = {yy}: {xx + yy}")

        print("\n")

        # Tracing is one useful way to understand what a schedule is
        # doing. You can also ask Halide to print out pseudocode
        # showing what loops Halide is generating:
        print("Pseudo-code for the schedule:")
        gradient.print_loop_nest()

        print()

        # Because we're using the default ordering, it should print:
        # compute gradient:
        #   for y:
        #     for x:
        #       gradient(...) = ...

    # Reorder variables.
    if True:
        gradient = hl.Func("gradient_col_major")
        gradient[x, y] = x + y
        gradient.trace_stores()

        # If we reorder x and y, we can walk down the columns
        # instead. The reorder call takes the arguments of the func,
        # and sets a new nesting order for the for loops that are
        # generated. The arguments are specified from the innermost
        # loop out, so the following call puts y in the inner loop:
        gradient.reorder(y, x)

        # This means y (the row) will vary quickly, and x (the
        # column) will vary slowly, so this is a column-major
        # traversal.

        print("Evaluating gradient column-major")
        gradient.realize([4, 4])

        print("Equivalent Python:")
        for xx in range(4):
            for yy in range(4):
                print(f"Evaluating at x = {xx}, y = {yy}: {xx + yy}")

        print()

        # If we print pseudo-code for this schedule, we'll see that
        # the loop over y is now inside the loop over x.
        print("Pseudo-code for the schedule:")
        gradient.print_loop_nest()

        print()

    # Split a variable into two.
    if True:
        gradient = hl.Func("gradient_split")
        gradient[x, y] = x + y
        gradient.trace_stores()

        # The most powerful primitive scheduling operation you can do
        # to a var is to split it into inner and outer sub-variables:
        x_outer, x_inner = hl.Var("x_outer"), hl.Var("x_inner")
        gradient.split(x, x_outer, x_inner, 2)

        # This breaks the loop over x into two nested loops: an outer
        # one over x_outer, and an inner one over x_inner. The last
        # argument to split was the "split factor". The inner loop
        # runs from zero to the split factor. The outer loop runs
        # from zero to the extent required of x (4 in this case)
        # divided by the split factor. Within the loops, the old
        # variable is defined to be outer * factor + inner. If the
        # old loop started at a value other than zero, then that is
        # also added within the loops.

        print("Evaluating gradient with x split into x_outer and x_inner ")
        gradient.realize([4, 4])

        print("Equivalent Python:")
        for yy in range(4):
            for x_outer in range(2):
                for x_inner in range(2):
                    xx = x_outer * 2 + x_inner
                    print(f"Evaluating at x = {xx}, y = {yy}: {xx + yy}")

        print()

        print("Pseudo-code for the schedule:")
        gradient.print_loop_nest()

        print()

        # Note that the order of evaluation of pixels didn't actually
        # change! Splitting by itself does nothing, but it does open
        # up all of the scheduling possibilities that we will explore
        # below.

    # Fuse two variables into one.
    if True:
        gradient = hl.Func("gradient_fused")
        gradient[x, y] = x + y

        # The opposite of splitting is 'fusing'. Fusing two variables
        # merges the two loops into a single for loop over the
        # product of the extents. Fusing is less important than
        # splitting, but it also sees use (as we'll see later in this
        # lesson). Like splitting, fusing by itself doesn't change
        # the order of evaluation.
        fused = hl.Var("fused")
        gradient.fuse(x, y, fused)

        print("Evaluating gradient with x and y fused")
        gradient.realize([4, 4])

        print("Equivalent Python:")
        for fused in range(4 * 4):
            yy = fused / 4
            xx = fused % 4
            print(f"Evaluating at x = {xx}, y = {yy}: {xx + yy}")

        print()

        print("Pseudo-code for the schedule:")
        gradient.print_loop_nest()

        print()

    # Evaluating in tiles.
    if True:
        gradient = hl.Func("gradient_tiled")
        gradient[x, y] = x + y
        gradient.trace_stores()

        # Now that we can both split and reorder, we can do tiled
        # evaluation. Let's split both x and y by a factor of two,
        # and then reorder the vars to express a tiled traversal.
        #
        # A tiled traversal splits the domain into small rectangular
        # tiles, and outermost iterates over the tiles, and within
        # that iterates over the points within each tile. It can be
        # good for performance if neighboring pixels use overlapping
        # input data, for example in a blur. We can express a tiled
        # traversal like so:
        x_outer, x_inner, y_outer, y_inner = hl.Var(), hl.Var(), hl.Var(), hl.Var()
        gradient.split(x, x_outer, x_inner, 2)
        gradient.split(y, y_outer, y_inner, 2)
        gradient.reorder(x_inner, y_inner, x_outer, y_outer)

        # This pattern is common enough that there's a shorthand for it:
        # gradient.tile(x, y, x_outer, y_outer, x_inner, y_inner, 2, 2)

        print("Evaluating gradient in 2x2 tiles")
        gradient.realize([4, 4])

        print("Equivalent Python:")
        for y_outer in range(2):
            for x_outer in range(2):
                for y_inner in range(2):
                    for x_inner in range(2):
                        xx = x_outer * 2 + x_inner
                        yy = y_outer * 2 + y_inner
                        print(f"Evaluating at x = {xx}, y = {yy}: {xx + yy}")

        print()

        print("Pseudo-code for the schedule:")
        gradient.print_loop_nest()

        print()

    # Evaluating in vectors.
    if True:
        gradient = hl.Func("gradient_in_vectors")
        gradient[x, y] = x + y
        gradient.trace_stores()

        # The nice thing about splitting is that it guarantees the
        # inner variable runs from zero to the split factor. Most of
        # the time the split-factor will be a compile-time constant,
        # so we can replace the loop over the inner variable with a
        # single vectorized computation. This time we'll split by a
        # factor of four, because on X86 we can use SSE to compute in
        # 4-wide vectors.
        x_outer, x_inner = hl.Var("x_outer"), hl.Var("x_inner")
        gradient.split(x, x_outer, x_inner, 4)
        gradient.vectorize(x_inner)

        # Splitting and then vectorizing the inner variable is common
        # enough that there's a short-hand for it. We could have also
        # said:
        #
        # gradient.vectorize(x, 4)
        #
        # which is equivalent to:
        #
        # gradient.split(x, x, x_inner, 4)
        # gradient.vectorize(x_inner)
        #
        # Note that in this case we reused the name 'x' as the new
        # outer variable. Later scheduling calls that refer to x
        # will refer to this new outer variable named x.

        # This time we'll evaluate over an 8x4 box, so that we have
        # more than one vector of work per scanline.
        print("Evaluating gradient with x_inner vectorized ")
        gradient.realize([8, 4])

        print("Equivalent Python:")
        for yy in range(4):
            for x_outer in range(2):
                # The loop over x_inner has gone away, and has been
                # replaced by a vectorized version of the
                # expression. On x86 processors, Halide generates SSE
                # for all of this.
                x_vec = [
                    x_outer * 4 + 0,
                    x_outer * 4 + 1,
                    x_outer * 4 + 2,
                    x_outer * 4 + 3,
                ]
                val = [
                    x_vec[0] + yy,
                    x_vec[1] + yy,
                    x_vec[2] + yy,
                    x_vec[3] + yy,
                ]
                print(
                    f"Evaluating at <{x_vec[0]}, {x_vec[1]}, {x_vec[2]}, {x_vec[3]}>, <{yy}, {yy}, {yy}, {yy}>: "
                    f"<{val[0]}, {val[1]}, {val[2]}, {val[3]}>"
                )

        print()

        print("Pseudo-code for the schedule:")
        gradient.print_loop_nest()

        print()

    # Unrolling a loop.
    if True:
        gradient = hl.Func("gradient_in_vectors")
        gradient[x, y] = x + y
        gradient.trace_stores()

        # If multiple pixels share overlapping data, it can make
        # sense to unroll a computation so that shared values are
        # only computed or loaded once. We do this similarly to how
        # we expressed vectorizing. We split a dimension and then
        # fully unroll the loop of the inner variable. Unrolling
        # doesn't change the order in which things are evaluated.
        x_outer, x_inner = hl.Var("x_outer"), hl.Var("x_inner")
        gradient.split(x, x_outer, x_inner, 2)
        gradient.unroll(x_inner)

        # The shorthand for this is:
        # gradient.unroll(x, 2)

        print("Evaluating gradient unrolled by a factor of two")
        result = gradient.realize([4, 4])

        print("Equivalent Python:")
        for yy in range(4):
            for x_outer in range(2):
                # Instead of a for loop over x_inner, we get two
                # copies of the innermost statement.
                if True:
                    x_inner = 0
                    xx = x_outer * 2 + x_inner
                    print(f"Evaluating at x = {xx}, y = {yy}: {xx + yy}")

                if True:
                    x_inner = 1
                    xx = x_outer * 2 + x_inner
                    print(f"Evaluating at x = {xx}, y = {yy}: {xx + yy}")

        print()

        print("Pseudo-code for the schedule:")
        gradient.print_loop_nest()

        print()

    # Splitting by factors that don't divide the extent.
    if True:
        gradient = hl.Func("gradient_split_5x4")
        gradient[x, y] = x + y
        gradient.trace_stores()

        # Splitting guarantees that the inner loop runs from zero to
        # the split factor, which is important for the uses we saw
        # above. So what happens when the total extent we wish to
        # evaluate x over isn't a multiple of the split factor? We'll
        # split by a factor of two again, but now we'll evaluate
        # gradient over a 5x4 box instead of the 4x4 box we've been
        # using.
        x_outer, x_inner = hl.Var("x_outer"), hl.Var("x_inner")
        gradient.split(x, x_outer, x_inner, 2)

        print("Evaluating gradient over a 5x4 box with x split by two ")
        gradient.realize([5, 4])

        print("Equivalent Python:")
        for yy in range(4):
            for x_outer in range(3):  # Now runs from 0 to 3
                for x_inner in range(2):
                    xx = x_outer * 2
                    # Before we add x_inner, make sure we don't
                    # evaluate points outside of the 5x4 box. We'll
                    # hl.clamp x to be at most 3 (5 minus the split
                    # factor).
                    if xx > 3:
                        xx = 3
                    xx += x_inner
                    print(f"Evaluating at x = {xx}, y = {yy}: {xx + yy}")

        print()

        print("Pseudo-code for the schedule:")
        gradient.print_loop_nest()

        print()

        # If you read the output, you'll see that some coordinates
        # were evaluated more than once! That's generally OK, because
        # pure Halide functions have no side-effects, so it's safe to
        # evaluate the same point multiple times. If you're calling out to
        # functions with side effects (like print) as we are here, it's
        # your responsibility to make sure you can handle the same point
        # being evaluated multiple times.

        # The general rule is: If we require x from x_min to x_min + x_extent, and
        # we split by a factor 'factor', then:
        #
        # x_outer runs from 0 to (x_extent + factor - 1)/factor
        # x_inner runs from 0 to factor
        # x = hl.min(x_outer * factor, x_extent - factor) + x_inner + x_min
        #
        # In our example, x_min was 0, x_extent was 5, and factor was 2.

        # However, if you write a Halide function with an update
        # definition (see lesson 9), then it is not safe to evaluate
        # the same point multiple times, so we won't apply this
        # trick. Instead the range of values computed will be rounded
        # up to the next multiple of the split factor.

    # Fusing, tiling, and parallelizing.
    if True:
        # We saw in the previous lesson that we can parallelize
        # across a variable. Here we combine it with fusing and
        # tiling to express a useful pattern - processing tiles in
        # parallel.

        # This is where fusing shines. Fusing helps when you want to
        # parallelize across multiple dimensions without introducing
        # nested parallelism. Nested parallelism (parallel for loops
        # within parallel for loops) is supported by Halide, but
        # often gives poor performance compared to fusing the
        # parallel variables into a single parallel for loop.

        gradient = hl.Func("gradient_fused_tiles")
        gradient[x, y] = x + y
        gradient.trace_stores()

        # First we'll tile, then we'll fuse the tile indices and
        # parallelize across the combination.
        x_outer, y_outer = hl.Var("x_outer"), hl.Var("y_outer")
        x_inner, y_inner = hl.Var("x_inner"), hl.Var("y_inner")
        tile_index = hl.Var("tile_index")
        gradient.tile(x, y, x_outer, y_outer, x_inner, y_inner, 2, 2)
        gradient.fuse(x_outer, y_outer, tile_index)
        gradient.parallel(tile_index)

        # The scheduling calls all return a reference to the hl.Func, so
        # you can also chain them together into a single statement to
        # make things slightly clearer:
        #
        # gradient
        #     .tile(x, y, x_outer, y_outer, x_inner, y_inner, 2, 2)
        #     .fuse(x_outer, y_outer, tile_index)
        #     .parallel(tile_index)

        print("Evaluating gradient tiles in parallel")
        gradient.realize([4, 4])

        # The tiles should occur in arbitrary order, but within each
        # tile the pixels will be traversed in row-major order.

        print("Equivalent (serial) Python:")
        # This outermost loop should be a parallel for loop, but that's
        # hard to express in plain Python.
        for tile_index in range(4):
            y_outer = tile_index / 2
            x_outer = tile_index % 2
            for y_inner in range(2):
                for x_inner in range(2):
                    yy = y_outer * 2 + y_inner
                    xx = x_outer * 2 + x_inner
                    print(f"Evaluating at x = {xx}, y = {yy}: {xx + yy}")

        print()

        print("Pseudo-code for the schedule:")
        gradient.print_loop_nest()

        print()

    # Putting it all together.
    if True:
        # Are you ready? We're going to use all of the features above now.
        gradient_fast = hl.Func("gradient_fast")
        gradient_fast[x, y] = x + y

        # We'll process 256x256 tiles in parallel.
        x_outer, y_outer = hl.Var("x_outer"), hl.Var("y_outer")
        x_inner, y_inner = hl.Var("x_inner"), hl.Var("y_inner")
        tile_index = hl.Var("tile_index")
        (
            gradient_fast.tile(x, y, x_outer, y_outer, x_inner, y_inner, 256, 256)  #
            .fuse(x_outer, y_outer, tile_index)
            .parallel(tile_index)
        )

        # We'll compute two scanlines at once while we walk across
        # each tile. We'll also vectorize in x. The easiest way to
        # express this is to recursively tile again within each tile
        # into 4x2 subtiles, then vectorize the subtiles across x and
        # unroll them across y:
        x_inner_outer, y_inner_outer = hl.vars("x_inner_outer y_inner_outer")
        x_vectors, y_pairs = hl.vars("x_vectors y_pairs")
        (
            gradient_fast.tile(
                x_inner, y_inner, x_inner_outer, y_inner_outer, x_vectors, y_pairs, 4, 2
            )  #
            .vectorize(x_vectors)
            .unroll(y_pairs)
        )

        # Note that we didn't do any explicit splitting or
        # reordering. Those are the most important primitive
        # operations, but mostly they are buried underneath tiling,
        # vectorizing, or unrolling calls.

        # Now let's evaluate this over a range which is not a
        # multiple of the tile size.

        # If you like you can turn on tracing, but it's going to
        # produce a lot of prints. Instead we'll compute the answer
        # both in plain Python and Halide and see if the answers match.
        result = gradient_fast.realize([800, 600])

        print("Checking Halide result against equivalent Python...")
        for tile_index in range(4 * 3):
            y_outer = tile_index // 4
            x_outer = tile_index % 4
            for y_inner_outer in range(256 // 2):
                for x_inner_outer in range(256 // 4):
                    # We're vectorized across x
                    xx = min(x_outer * 256, 800 - 256) + x_inner_outer * 4
                    x_vec = [xx + 0, xx + 1, xx + 2, xx + 3]

                    # And we unrolled across y
                    y_base = min(y_outer * 256, 600 - 256) + y_inner_outer * 2

                    if True:
                        # y_pairs = 0
                        yy = y_base + 0
                        y_vec = [yy, yy, yy, yy]
                        val = [
                            x_vec[0] + y_vec[0],
                            x_vec[1] + y_vec[1],
                            x_vec[2] + y_vec[2],
                            x_vec[3] + y_vec[3],
                        ]

                        # Check the result.
                        for i in range(4):
                            assert result[x_vec[i], y_vec[i]] == val[i], (
                                f"There was an error at {x_vec[i]} {y_vec[i]}!"
                            )

                    if True:
                        # y_pairs = 1
                        yy = y_base + 1
                        y_vec = [yy, yy, yy, yy]
                        val = [
                            x_vec[0] + y_vec[0],
                            x_vec[1] + y_vec[1],
                            x_vec[2] + y_vec[2],
                            x_vec[3] + y_vec[3],
                        ]

                        # Check the result.
                        for i in range(4):
                            assert result[x_vec[i], y_vec[i]] == val[i], (
                                f"There was an error at {x_vec[i]} {y_vec[i]}!"
                            )

        print()

        print("Pseudo-code for the schedule:")
        gradient_fast.print_loop_nest()

        print()

        # Note that in the Halide version, the algorithm is specified
        # once at the top, separately from the optimizations, and there
        # aren't that many lines of code total. Compare this to the
        # plain Python version above. There's more code (and it isn't
        # even parallelized or vectorized properly). More annoyingly,
        # the statement of the algorithm (the result is x plus y) is
        # buried in multiple places within the mess. This plain Python
        # code is hard to write, hard to read, hard to debug, and hard
        # to optimize further. This is why Halide exists.

    print("Success!")
    return 0


if __name__ == "__main__":
    main()
